this is chm-650, a high-speed and good-performance pick and place machine of hunan charmhigh electromechanical equipment co., ltd.
chm-650 pick and place machine is characterized by 50 feeder stacks, 4 heads capable of 360-degree rotation,
support for yamaha pneumatic feeders ,stick feeders with tubular components, automatic correction to pick components,
integrated operation with built-in industrial computer.
chm-650 parameters
| chm-650 specifications | |
| dimensions | 1280mm(l)×1190mm(w)×1050mm(h) |
| weight | 310kg |
| power supply | ac220v (50hz, single phase), 2.1kw |
| air supply | 0.5mpa ~0.7mpa |
| vacuum generation | vacuum generator |
| mounting head quantity | 4 |
| mounting speed | 9000cph(optimal) |
| mounting accuracy | ±50μm@μ±3σ/chip |
| control accuracy | 5μm |
| component height | 12mm |
| component type | 0201/0402/0603~5050/sot/sop/qfp/qfn/bga, etc. (resistor/capacitor/diode/triode/led/ic, etc.) |
| pcb thickness | 0.6mm~3.5mm |
| pcb size | 400mm(l)×350mm(w) |
| pcb conveying | 3-section-rail automatic conveying |
| nozzle change | automatic nozzle change (19-hole nozzle library) |
| control system | built-in industrial computer (windows 7) equipped with monitor, keyboard, and mouse |
| drive system | x&y axis driven by servo motors; adopting flexible s-curve acceleration and deceleration |
| transmission system | ball screw linear guide |
| feeding system | 50 yamaha 8mm standard pneumatic/electric feeder stacks (also suitable for ic tray and stick feeder) |
| vision system | snapshot camera×4 (component size applicable: 16mm×16mm); ic camera×1 (component size applicable: 36mm×36mm); mark camera×2 |
